Perimeter LED display -BGLOPTO

Perimeter Display

Our LED perimeter display is specifically designed for sports venues and stadiums to enhance the viewing experience for spectators and provide engaging content during event. It can used in various sports such as soccer, basketball, rugby, cricket and more. Additionally, it can be utilized for concerts, corporate events, trade shows, and other gatherings where visual communication is key.

Characteristic

Low power consumption.

High refreshing more than 3840Hz.

High brightness.

Higher installation efficiency and less labor cost.

Waterproof IP66.

Support both front and rear maintenance.

Specifications

Accessory

Gallery

Model	Perimeter6	Perimeter8	Perimeter10
Pixel Pitch-mm	6.67	8	10
Pixel Density-pixels/m2	22,500	15;625	10;000
LED type	SMD2727	SMD2727	SMD2727
Module Dimension	480 x 320mm	480 x 320mm	480 x 320mm
Module Resolution	72 x 48	60 x 40	48 x 32
Panel Dimension	960 x 960 x 88mm	960 x 960 x 88mm	960 x 960 x 88mm
Panel Resolution	144 x 144	120 x 120	96 x 96
Panel Weight	25.5kgs	25.5kgs	25.5kgs
Typical Brightness(nits)	6000~10000	6000~10000	6000~10000
Viewing Angle	H140°/V120°	H140°/V120°	H140°/V120°
Refresh Rate	≥3840Hz	≥3840Hz	≥3840Hz
Operating Power Source	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz
Max. Power Consumption (W/m²)	430	435	439
Avg. Power Consumption (W/m²)	142	143.5	144
Serviceability	Front&Rear	Front&Rear	Front&Rear
IP Rating	IP66(Outdoor)	IP66(Outdoor)	IP66(Outdoor)
Operating Temp/Humidity	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH
Storage Temp/Humidity	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH
Life Span	100,000 h	100,000 h	100,000 h

Note: The Specifications are for reference, actual values may vary.
