Rz Series Indoor&Outdoor -BGLOPTO

Rz Series Indoor&Outdoor

Rz Series, an ideal solution for the rental industry with its different sizes, like the 500x500mm and 500x1000mm. With its modular design, you can easily create straight angles and cube formations to elevate your visual presentations.

Combined with exceptional image quality and reliability, our LED display is ultimate solution for captivating your audience and making a lasting impact at any event.

Characteristic

Creative for straight angle display.

Modular design with easy maintenance.

Both indoor and outdoor available.

High contrast ratio and gray scale.

High refresh rate.

Specifications

Accessory

Gallery

Model	Rz1.9i	Rz2.6i	Rz2.9i	Rz3.9i
Rz Series Indoor
Pixel Pitch-mm	1.9	2.6	2.97	3.91
Pixel Density-pixels/m2	277,008	147,929	113,367	65,410
LED type	SMD1515	SMD1515	SMD1515	SMD2020
Module Dimension	250 x 250mm	250 x 250mm	250 x 250mm	250 x 250mm
Module Resolution	128 x 128	96 x 96	84 x 84	64 x 64
Panel Dimension（2 sizes）	500 x 500 x 88mm 500 x 1000 x 88mm	500 x 500 x 88mm 500 x 1000 x 88mm	500 x 500 x 88mm 500 x 1000 x 88mm	500 x 500 x 88mm 500 x 1000 x 88mm
Panel Resolution	256 x 256, 256 x 512	192 x 192, 192 x 384	168 x 168, 168 x 336	128 x 128, 128 x 256
Panel Weight	8.5 kg, 13kg	8.5 k,g 13kg	8.5 kg, 13kg	8.5 kg, 13kg
Typical Brightness(nits)	800	1000	1000	1000
Viewing Angle	H160°/V160°	H160°/V140°	H160°/V140°	H160°/V140°
Refresh Rate	≥3840Hz	≥3840Hz	≥3840Hz	≥3840Hz
Operating Power Source	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz
Max. Power Consumption (W/m²)	712	730	728	722
Avg. Power Consumption (W/m²)	228	234	233	231
Serviceability	Front&Rear	Front&Rear	Front&Rear	Front&Rear
IP Rating	IP43(Indoor)	IP43(Indoor)	IP43(Indoor)	IP43(Indoor)
Operating Temp/Humidity	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH
Storage Temp/Humidity	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH
Life Span	100,000 h	100,000 h	100,000 h	100,000 h
Curving (Optional curved locks)	YES	YES	YES	YES

Note: The Specifications are for reference, actual values may vary.

Model	Rz2.9O	Rz3.9O	Rz4.8O
Rz Series Outdoor
Pixel Pitch-mm	2.97	3.91	4.8
Pixel Density-pixels/m2	112,896	65,410	43,403
LED type	SMD1415	SMD1921	SMD1921
Module Dimension	250 x 250mm	250 x 250mm	250 x 250mm
Module Resolution	84 x 84	64 x 64	52 x 52
Panel Dimension（2 sizes）	500 x 500 x 88mm 500 x 1000 x 88mm	500 x 500 x 88mm 500 x 1000 x 88mm	500 x 500 x 88mm 500 x 1000 x 88mm
Panel Resolution	168 x 168, 168 x 336	128 x 128, 128 x 256	104 x 104, 104 x 208
Panel Weight	8.5 kg, 13kg	8.5 kg, 13kg	8.5 kg, 13kg
Typical Brightness(nits)	4500	5500	5500
Viewing Angle	H160°/V140°	H160°/V140°	H160°/V140°
Refresh Rate	≥3840Hz	≥3840Hz	≥3840Hz
Operating Power Source	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz
Max. Power Consumption (W/m²)	750	750	762
Avg. Power Consumption (W/m²)	240	240	244
Serviceability	Front&Rear	Front&Rear	Front&Rear
IP Rating	IP65(Outdoor)	IP65(Outdoor)	IP65(Outdoor)
Operating Temp/Humidity	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH
Storage Temp/Humidity	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH
Life Span	100,000 h	100,000 h	100,000 h
Curving (Optional curved locks)	YES	YES	YES

Note: The Specifications are for reference, actual values may vary.
