FS Series SMD Outdoor

The SMD-LED outdoor video display offering high resolution 2.97mm pixel pitch for short viewing distance, and light weight is competitive transportation and quick installation, low purchase and maintenance cost, an efficient energy management and high quality LEDs with long durability make the video display economically attractive.

Characteristic

HD outdoor display

Refresh rate ≥3840Hz.

Cabinet size 500x1000mm for quick installation.

Special module design for full front and rear maintenance.

Specifications

Accessory

Gallery


Model FS2.9O
Pixel Pitch-mm 2.97
Pixel Density-pixels/m2 112896
LED type SMD1415
Module Dimension 250 x 250mm
Module Resolution 84 x 84
Panel Dimension（2 sizes） 500 x 500 mm
500 x 1000mm
Panel Resolution 168 x 168 168 x 336
Panel Weight  8.56 kg 13.6kg
Typical Brightness(nits) ≥5000
Viewing Angle H140°/V140°
Refresh Rate ≥3840Hz
Operating Power Source 100 - 240 V, 50 - 60 Hz
Max. Power Consumption (W/m²) 600
Avg. Power Consumption  (W/m²) 210
Serviceability Front&Rear
IP Rating IP65(Outdoor)
Operating Temp/Humidity -20°~ 55°C, 10~90% RH
Storage Temp/Humidity -40°~ 60°C, 10~90% RH
Life Span 100,000 h

Note: The Specifications are for reference, actual values may vary.
