RC Series-Rental Display

Specifications

Accessory

Gallery

Model	RC1.9	RC2.6	RC2.97	RC3.91
Pixel Pitch-mm	1.9	2.6	2.97	3.91
Pixel Density-pixels/m2	277008	147929	113367	65410
LED type	SMD1515	SMD1515	SMD1515	SMD2020
Module Dimension	250 x 250mm	250 x 250mm	250 x 250mm	250 x 250mm
Module Resolution	128 x 128	96 x 96	84 x 84	64 x 64
Panel Dimension（2 sizes）	500 x 500 x 78mm 500 x 1000 x 78mm	500 x 500 x 78mm 500 x 1000 x 78mm	500 x 500 x 78mm 500 x 1000 x 78mm	500 x 500 x 78mm 500 x 1000 x 78mm
Panel Resolution	256 x 256 256 x 512	192 x 192 192 x 384	168 x 168 168 x 336	128 x 128 128 x 256
Panel Weight	8.5 kg 13kg	8.5 kg 13kg	8.5 kg 13kg	8.5 kg 13kg
Typical Brightness(nits)	800	1000	1000	1000
Viewing Angle	H160°/V160°	H160°/V140°	H160°/V140°	H160°/V140°
Refresh Rate	≥3840Hz	≥3840Hz	≥3840Hz	≥3840Hz
Operating Power Source	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz	100 - 240 V, 50 - 60 Hz
Max. Power Consumption (W/m²)	712	730	728	722
Avg. Power Consumption (W/m²)	228	234	233	231
Serviceability	Front&Rear Mounting on wall	Front&Rear Mounting on wall	Front&Rear Mounting on wall	Front&Rear Mounting on wall
IP Rating	IP43(Indoor)	IP43(Indoor)	IP43(Indoor)	IP43(Indoor)
Operating Temp/Humidity	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH	-20°~ 55°C, 10~90% RH
Storage Temp/Humidity	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH	-40°~ 60°C, 10~90% RH
Life Span	100,000 h	100,000 h	100,000 h	100,000 h
Curving (Optional curved locks)	YES	YES	YES	YES

Note: The Specifications are for reference, actual values may
