| Model | BTP3.9-7.8 | BTP3.9-7.8 |
|---|---|---|
| Pixel Pitch-mm | 3.91-7.81mm | 3.91-7.81mm |
| Pixel Density-pixels/m2 | 32768 | 32768 |
| LED type | SMD1921 | SMD1921 |
| Module Dimension | 500x 62.5mm | 500x 62.5mm |
| Module Resolution | 128 x 8 | 128 x 8 |
| Panel Dimension | 500 x 1000 x 68mm | 500 x 1000 x 68mm |
| Panel Resolution | 256 x 64 | 256 x 64 |
| Panel Weight | 5.5 kg | 5.5 kg |
| Typical Brightness(nits) | 5000 | 2500 |
| Viewing Angle | H160°/V140° | H160°/V140° |
| Refresh Rate | ≥3840Hz | ≥3840Hz |
| Operating Power Source | 100 - 240 V, 50 - 60 Hz | 100 - 240 V, 50 - 60 Hz |
| Max. Power Consumption (W/m²) | 750 | 720 |
| Avg. Power Consumption (W/m²) | 240 | 230 |
| Serviceability | Front&Rear | Front&Rear |
| IP Rating | IP65(Outdoor) | IP65(Outdoor) |
| Operating Temp/Humidity | -20°~ 55°C, 10~90% RH | -20°~ 55°C, 10~90% RH |
| Storage Temp/Humidity | -40°~ 60°C, 10~90% RH | -40°~ 60°C, 10~90% RH |
| Life Span | 100,000 h | 100,000 h |
| Curving (Optional curved locks) | YES | YES |
Note: The Specifications are for reference, actual values may vary.
